Name: Stainless Steel Hardware Fasteners Fully Threaded Plain Hex Bolt Hexagon Head Bolt DIN 933
Brand: mxfastener
Price: 0.40 USD
Availability: InStock

Products / Stainless Steel Hardware Fasteners Fully Threaded Plain Hex Bolt Hexagon Head Bolt DIN 933

Product description

Stainless Steel Hardware Fasteners Fully Threaded Plain Hex Bolt Hexagon Head Bolt DIN 933

Screw Thread
d

M1.6

M2.5

(M3.5)

(M7)

M10

M12

(M14)

M16

P	Pitch
a	max
c	min
	max
da	max
dw	Grade A	min
	Grade B	min
e	Grade A	min
	Grade B	min
k	Nominal Size
	Grade A	min
		max
	Grade B	min
		max
k1	min
r	min
s	max=nominal size
	Grade A	min
	Grade B	min

0.35	0.4	0.45	0.5	0.6	0.7	0.8	1	1	1.25	1.5	1.75	2	2
1.05	1.2	1.35	1.5	1.8	2.1	2.4	3	3	3.75	4.5	5.25	6	6
0.1	0.1	0.1	0.15	0.15	0.15	0.15	0.15	0.15	0.15	0.15	0.15	0.15	0.2
0.25	0.25	0.25	0.4	0.4	0.4	0.5	0.5	0.5	0.6	0.6	0.6	0.6	0.8
2	2.6	3.1	3.6	4.1	4.7	5.7	6.8	7.8	9.2	11.2	13.7	15.7	17.7
2.4	3.2	4.1	4.6	5.1	5.9	6.9	8.9	9.6	11.6	15.6	17.4	20.5	22.5
-	-	-	-	-	5.7	6.7	8.7	9.4	11.4	15.4	17.2	20.1	22
3.41	4.32	5.45	6.01	6.58	7.66	8.79	11.05	12.12	14.38	18.9	21.1	24.49	26.75
-	-	-	-	-	7.5	8.63	10.89	11.94	14.2	18.72	20.88	23.91	26.17
1.1	1.4	1.7	2	2.4	2.8	3.5	4	4.8	5.3	6.4	7.5	8.8	10
0.98	1.28	1.58	1.88	2.28	2.68	3.35	3.85	4.65	5.15	6.22	7.32	8.62	9.82
1.22	1.52	1.82	2.12	2.52	2.92	3.65	4.15	4.95	5.45	6.56	7.68	8.98	10.18
-	-	-	-	-	2.6	3.26	3.76	4.56	5.06	6.11	7.21	8.51	9.71
-	-	-	-	-	3	3.74	4.24	5.04	5.54	6.69	7.79	9.09	10.29
0.7	0.9	1.1	1.3	1.6	1.9	2.28	2.63	3.19	3.54	4.28	5.05	5.96	6.8
0.1	0.1	0.1	0.1	0.1	0.2	0.2	0.25	0.25	0.4	0.4	0.6	0.6	0.6
3.2	4	5	5.5	6	7	8	10	11	13	17	19	22	24
3.02	3.82	4.82	5.32	5.82	6.78	7.78	9.78	10.73	12.73	16.73	18.67	21.67	23.67
-	-	-	-	-	6.64	7.64	9.64	10.57	12.57	16.57	18.48	21.16	23.16

Detailed Photos

About MIANXUAN

Stainless Steel Hardware Fasteners Fully Threaded Plain Hex Bolt Hexagon Head Bolt DIN 933
