DIN 933 Hex Bolt A2 A4 Full Thread Stainless Steel Hexagon Head Bolt

Product description

DIN 933 Hex Bolt A2 A4 Full Thread Stainless Steel Hexagon Head Bolt

Screw Thread
d
M1.6 M2 M2.5 M3 (M3.5) M4 M5 M6 (M7) M8 M10 M12 (M14) M16
P Pitch
a max
c min
max
da max
dw Grade A min
Grade B min
e Grade A min
Grade B min
k Nominal Size
Grade A min
max
Grade B min
max
k1 min
r min
s max=nominal size
Grade A min
Grade B min
0.35 0.4 0.45 0.5 0.6 0.7 0.8 1 1 1.25 1.5 1.75 2 2
1.05 1.2 1.35 1.5 1.8 2.1 2.4 3 3 3.75 4.5 5.25 6 6
0.1 0.1 0.1 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.15 0.2
0.25 0.25 0.25 0.4 0.4 0.4 0.5 0.5 0.5 0.6 0.6 0.6 0.6 0.8
2 2.6 3.1 3.6 4.1 4.7 5.7 6.8 7.8 9.2 11.2 13.7 15.7 17.7
2.4 3.2 4.1 4.6 5.1 5.9 6.9 8.9 9.6 11.6 15.6 17.4 20.5 22.5
- - - - - 5.7 6.7 8.7 9.4 11.4 15.4 17.2 20.1 22
3.41 4.32 5.45 6.01 6.58 7.66 8.79 11.05 12.12 14.38 18.9 21.1 24.49 26.75
- - - - - 7.5 8.63 10.89 11.94 14.2 18.72 20.88 23.91 26.17
1.1 1.4 1.7 2 2.4 2.8 3.5 4 4.8 5.3 6.4 7.5 8.8 10
0.98 1.28 1.58 1.88 2.28 2.68 3.35 3.85 4.65 5.15 6.22 7.32 8.62 9.82
1.22 1.52 1.82 2.12 2.52 2.92 3.65 4.15 4.95 5.45 6.56 7.68 8.98 10.18
- - - - - 2.6 3.26 3.76 4.56 5.06 6.11 7.21 8.51 9.71
- - - - - 3 3.74 4.24 5.04 5.54 6.69 7.79 9.09 10.29
0.7 0.9 1.1 1.3 1.6 1.9 2.28 2.63 3.19 3.54 4.28 5.05 5.96 6.8
0.1 0.1 0.1 0.1 0.1 0.2 0.2 0.25 0.25 0.4 0.4 0.6 0.6 0.6
3.2 4 5 5.5 6 7 8 10 11 13 17 19 22 24
3.02 3.82 4.82 5.32 5.82 6.78 7.78 9.78 10.73 12.73 16.73 18.67 21.67 23.67
- - - - - 6.64 7.64 9.64 10.57 12.57 16.57 18.48 21.16 23.16
